KST42MTF データシート

Name: KST42MTF
Brand: FAIRCHILD
SKU: 210002132-0000-0000-0000

KST42MTF - FAIRCHILD の商品詳細ページです。

２営業日以内に回答いたします

KST42MTF の詳細情報

型番	KST42MTF
メーカー	FAIRCHILD
データシート
Collector Current-Max (IC)	0.5 A
Collector-emitter Voltage-Max	300 V
Configuration	SINGLE
DC Current Gain-Min (hFE)	40
JESD-30 Code	R-PDSO-G3
JESD-609 Code	e3
Moisture Sensitivity Level	1
Number of Elements	1
Number of Terminals	3
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Polarity/Channel Type	NPN
Power Dissipation-Max (Abs)	350 W
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	YES
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Transistor Element Material	SILICON
Transition Frequency-Nom (fT)	50 MHz

会社名称	Fairchild Semiconductor Corporation
設立	1957
所在地	3030 Orchard Parkway San Jose, CA 95134 United States
URL	http://www.fairchildsemi.com/
