KA7541
データシート
1
-
- 個
２営業日以内に回答いたします
KA7541 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | KA7541 |
|---|---|
| メーカー | FAIRCHILD |
| データシート |  |
| Analog IC - Other Type | FLUORESCENT LIGHT CONTROLLER |
| Control Mode | VOLTAGE-MODE |
| Control Technique | PULSE FREQUENCY MODULATION |
| Input Voltage-Max | 25 V |
| Input Voltage-Min | 8.7 V |
| Input Voltage-Nom | 14 V |
| JESD-30 Code | R-PDIP-T8 |
| JESD-609 Code | e3 |
| Length | 4.9 mm |
| Moisture Sensitivity Level | 1 |
| Number of Functions | 1 |
| Number of Terminals | 8 |
| Operating Temperature-Max | 105 Cel |
| Operating Temperature-Min | -25 Cel |
| Output Current-Max | 0.3 A |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | DIP |
| Package Equivalence Code | DIP8,.3 |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Qualification Status | Not Qualified |
| Seated Height-Max | 1.75 mm |
| Sub Category | Switching Regulator or Controllers |
| Surface Mount | NO |
| Switcher Configuration | PUSH-PULL |
| Switching Frequency-Max | 56 kHz |
| Technology | BIPOLAR |
| Temperature Grade | OTHER |
| Terminal Finish | MATTE TIN |
| Terminal Form | GULL WING |
| Terminal Pitch | 1.27 mm |
| Terminal Position | DUAL |
| Width | 3.9 mm |
| 会社名称 | Fairchild Semiconductor Corporation |
|---|---|
| 設立 | 1957 |
| 所在地 | 3030 Orchard Parkway San Jose, CA 95134 United States |
| URL | http://www.fairchildsemi.com/ |
KA7541のレビュー
KA7541 のご注文について
050-3612-7934
045-263-9989
KA7541 - FAIRCHILD の商品詳細ページです。
