KA3843ACS データシート Fairchild

KA3843ACS - FAIRCHILD の商品詳細ページです。

1
No Image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

KA3843ACS の詳細情報

  • 仕様・詳細
  • メーカー情報
型番KA3843ACS
メーカーFAIRCHILD
データシートProduct_list_pdf
Analog IC - Other Type SWITCHING CONTROLLER
Control Mode CURRENT-MODE
Control Technique PULSE WIDTH MODULATION
Input Voltage-Max 29 V
Input Voltage-Nom 15 V
JESD-30 Code R-PDSO-G8
JESD-609 Code e3
Length 4.9 mm
Number of Functions 1
Number of Terminals 8
Operating Temperature-Max 70 Cel
Operating Temperature-Min 0 Cel
Output Current-Max 1 A
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code DIP8,.3
Package Shape RECTANGULAR
Package Style SMALL OUTLINE Meter
Qualification Status Not Qualified
Seated Height-Max 1.75 mm
Sub Category Switching Regulator or Controllers
Surface Mount YES
Switcher Configuration PUSH-PULL
Switching Frequency-Max 500 kHz
Technology BIPOLAR
Temperature Grade COMMERCIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Width 3.9 mm
会社名称Fairchild Semiconductor Corporation
設立1957
所在地3030 Orchard Parkway San Jose, CA 95134 United States
URLhttp://www.fairchildsemi.com/
