FSDM311A データシート

Name: FSDM311A
Brand: FAIRCHILD
SKU: 160031605-0000-0000-0000

FSDM311A - FAIRCHILD の商品詳細ページです。

２営業日以内に回答いたします

FSDM311A の詳細情報

型番	FSDM311A
メーカー	FAIRCHILD
データシート
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	VOLTAGE-MODE
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Min	8 V
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e3
Length	9.415 mm
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-25 Cel
Output Current-Max	1.5 A
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP8,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Qualification Status	Not Qualified
Seated Height-Max	5.08 mm
Sub Category	Switching Regulator or Controllers
Supply Current-Max (Isup)	3 mA
Surface Mount	NO
Switcher Configuration	SINGLE
Switching Frequency-Max	73 kHz
Temperature Grade	OTHER
Terminal Finish	MATTE TIN
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Width	7.62 mm
