FDS6675BZ データシート

Name: FDS6675BZ
Brand: FAIRCHILD
SKU: 160006889-0000-0000-0000

FDS6675BZ - FAIRCHILD の商品詳細ページです。

２営業日以内に回答いたします

FDS6675BZ の詳細情報

型番	FDS6675BZ
メーカー	FAIRCHILD
データシート
Configuration	SINGLE WITH BUILT-IN DIODE
DS Breakdown Voltage-Min	30 V
Drain Current-Max (Abs) (ID)	11 A
Drain Current-Max (ID)	11 A
Drain-source On Resistance-Max	0.013 ohm
FET Technology	METAL-OXIDE SEMICONDUCTOR
Feedback Cap-Max (Crss)	500 pF
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e3
Moisture Sensitivity Level	1
Number of Elements	1
Number of Terminals	8
Operating Mode	ENHANCEMENT MODE
Operating Temperature-Max	150 Cel
Operating Temperature-Min	-55 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Polarity/Channel Type	P-CHANNEL
Power Dissipation-Max (Abs)	2.5 W
Pulsed Drain Current-Max (IDM)	55 A
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	YES
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Transistor Application	SWITCHING
Transistor Element Material	SILICON
Turn-off Time-Max (toff)	300 ns
Turn-on Time-Max (ton)	26 ns

会社名称	Fairchild Semiconductor Corporation
設立	1957
所在地	3030 Orchard Parkway San Jose, CA 95134 United States
URL	http://www.fairchildsemi.com/
