74VHC14MTCX データシート

Name: 74VHC14MTCX
Brand: FAIRCHILD
SKU: 80005345-0000-0000-0000

74VHC14MTCX - FAIRCHILD の商品詳細ページです。

２営業日以内に回答いたします

CMOS標準ロジックIC

74VHC14MTCX の詳細情報

型番	74VHC14MTCX
メーカー	FAIRCHILD
種別	CMOS標準ロジックIC
データシート
Family	AHC/VHC
JESD-30 Code	R-PDSO-G14
JESD-609 Code	e3
Length	5 mm
Load Capacitance (CL)	50 pF
Logic IC Type	INVERTER
Max I(ol)	0.008 Amp
Moisture Sensitivity Level	1
Number of Functions	6
Number of Inputs	1
Number of Terminals	14
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP14,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Power Supplies	2/5.5 V
Prop. Delay@Nom-Sup	12 ns
Propagation Delay (tpd)	12 ns
Qualification Status	Not Qualified
Schmitt Trigger	YES
Seated Height-Max	1.1 mm
Sub Category	Gates
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	2 V
Supply Voltage-Nom (Vsup)	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	4.4 mm

会社名称	Fairchild Semiconductor Corporation
設立	1957
所在地	3030 Orchard Parkway San Jose, CA 95134 United States
URL	http://www.fairchildsemi.com/
