1N968B
データシート
1
-
- 個
２営業日以内に回答いたします
1N968B の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | 1N968B |
|---|---|
| メーカー | FAIRCHILD |
| データシート |  |
| Additional Feature | HIGH RELIABILITY |
| Case Connection | ISOLATED |
| Configuration | SINGLE |
| Diode Element Material | SILICON |
| Diode Type | ZENER DIODE |
| Dynamic Impedance-Max | 25 ohm |
| Forward Voltage-Max (VF) | 1.1 V |
| JEDEC-95 Code | DO-7 |
| JESD-30 Code | O-GALF-W2 |
| JESD-609 Code | e0 |
| Knee Impedance-Max | 700 ohm |
| Moisture Sensitivity Level | 1 |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Operating Temperature-Max | 175 Cel |
| Operating Temperature-Min | -65 Cel |
| Package Body Material | CERAMIC, GLASS-SEALED |
| Package Shape | ROUND |
| Package Style | LONG FORM Meter |
| Peak Reflow Temperature (Cel) | 240 |
| Polarity | UNIDIRECTIONAL |
| Power Dissipation-Max | 0.4 W |
| Qualification Status | Not Qualified |
| Reference Standard | MIL-19500 |
| Reference Voltage-Nom | 20 V |
| Reverse Current-Max | 0.005 uA |
| Reverse Test Voltage | 15 V |
| Sub Category | Voltage Reference Diodes |
| Surface Mount | NO |
| Technology | ZENER |
| Terminal Finish | MATTE TIN |
| Terminal Form | WIRE |
| Terminal Position | AXIAL |
| Time@Peak Reflow Temperature-Max (s) | 10 |
| Voltage Temp Coeff-Max | 17.2 mV/Cel |
| Voltage Tol-Max | 5 % |
| Working Test Current | 6.2 mA |
| 会社名称 | Fairchild Semiconductor Corporation |
|---|---|
| 設立 | 1957 |
| 所在地 | 3030 Orchard Parkway San Jose, CA 95134 United States |
| URL | http://www.fairchildsemi.com/ |
1N968Bのレビュー
1N968B のご注文について
050-3612-7934
045-263-9989
1N968B - FAIRCHILD の商品詳細ページです。
