100112DC
1
-
- 個
２営業日以内に回答いたします
100112DC の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | 100112DC |
|---|---|
| メーカー | FAIRCHILD |
| Additional Feature | STROBED O/P'S |
| Family | 100K |
| JESD-30 Code | R-GDIP-T24 |
| JESD-609 Code | e0 |
| Length | 30.57 mm |
| Load Capacitance (CL) | 3 pF |
| Logic IC Type | INVERTER/BUFFER |
| Number of Functions | 4 |
| Number of Inputs | 1 |
| Number of Terminals | 24 |
| Operating Temperature-Max | 85 Cel |
| Operating Temperature-Min | 0 Cel |
| Output Characteristics | OPEN-EMITTER |
| Package Body Material | CERAMIC, GLASS-SEALED |
| Package Code | DIP |
| Package Shape | RECTANGULAR |
| Package Style | IN-LINE Meter |
| Power Supply Current-Max (ICC) | 106 mA |
| Propagation Delay (tpd) | 1.6 ns |
| Qualification Status | Not Qualified |
| Seated Height-Max | 5.08 mm |
| Surface Mount | NO |
| Technology | ECL |
| Temperature Grade | OTHER |
| Terminal Finish | TIN LEAD |
| Terminal Form | THROUGH-HOLE |
| Terminal Pitch | 2.54 mm |
| Terminal Position | DUAL |
| Width | 10.16 mm |
| 会社名称 | Fairchild Semiconductor Corporation |
|---|---|
| 設立 | 1957 |
| 所在地 | 3030 Orchard Parkway San Jose, CA 95134 United States |
| URL | http://www.fairchildsemi.com/ |
