M12L64322A-6TIG2S
1
-
- 個
２営業日以内に回答いたします
M12L64322A-6TIG2S の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | M12L64322A-6TIG2S |
|---|---|
| メーカー | ESMT |
| Access Mode | FOUR BANK PAGE BURST |
| Access Time-Max | 5 ns |
| Additional Feature | AUTO/SELF REFRESH |
| Clock Frequency-Max (fCLK) | 166 MHz |
| I/O Type | COMMON |
| Interleaved Burst Length | 1,2,4,8 |
| JESD-30 Code | R-PDSO-G86 |
| Length | 22.22 mm |
| Memory Density | 67108864 bit |
| Memory IC Type | SYNCHRONOUS DRAM |
| Memory Width | 32 |
| Number of Functions | 1 |
| Number of Ports | 1 |
| Number of Terminals | 86 |
| Number of Words | 2097152 words |
| Number of Words Code | 2M |
| Operating Mode | SYNCHRONOUS |
| Operating Temperature-Max | 85 Cel |
| Operating Temperature-Min | -40 Cel |
| Organization | 2MX32 |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | TSOP2 |
| Package Equivalence Code | TSSOP86,.46,20 |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE, THIN PROFILE Meter |
| Refresh Cycles | 4096 |
| Seated Height-Max | 1.2 mm |
| Self Refresh | YES |
| Sequential Burst Length | 1,2,4,8,FP |
| Standby Current-Max | 0.002 Amp |
| Supply Current-Max | 0.31 mA |
| Supply Voltage-Max (Vsup) | 3.6 V |
| Supply Voltage-Min (Vsup) | 3 V |
| Supply Voltage-Nom (Vsup) | 3.3 V |
| Surface Mount | YES |
| Technology | CMOS |
| Terminal Form | GULL WING |
| Terminal Pitch | 0.5 mm |
| Terminal Position | DUAL |
| Width | 10.16 mm |
| 会社名称 | Elite Semiconductor Memory Technology Inc. |
|---|---|
| 設立 | 1998 |
| 所在地 | No.23, Industry E Rd. IV Science-Based Industrial Park,Hsinchu 300, Taiwan, R.O.C. |
| URL | http://www.esmt.com.tw |
