F49L320UA-70TG Esmt

F49L320UA-70TG - ESMT の商品詳細ページです。

1
F49L320UA-70TG
  • F49L320UA-70TG
  • F49L320UA-70TG
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

F49L320UA-70TG の詳細情報

  • 仕様・詳細
  • メーカー情報
型番F49L320UA-70TG
メーカーESMT
Access Time-Max 70 ns
Alternate Memory Width 8
Boot Block TOP
JESD-30 Code R-PDSO-G48
Length 18.4 mm
Memory Density 33554432 bit
Memory IC Type FLASH
Memory Width 8
Number of Functions 1
Number of Terminals 48
Number of Words 2097152 words
Number of Words Code 2M
Operating Mode ASYNCHRONOUS
Operating Temperature-Max 70 Cel
Operating Temperature-Min 0 Cel
Organization 2MX16
Package Body Material PLASTIC/EPOXY
Package Code TSOP1
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE Meter
Parallel/Serial PARALLEL
Programming Voltage 3 V
Qualification Status Not Qualified
Seated Height-Max 1.2 mm
Supply Voltage-Max (Vsup) 3.6 V
Supply Voltage-Min (Vsup) 2.7 V
Supply Voltage-Nom (Vsup) 3 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Form GULL WING
Terminal Pitch 0.5 mm
Terminal Position DUAL
Type NOR TYPE
Width 12 mm
会社名称Elite Semiconductor Memory Technology Inc.
設立1998
所在地No.23, Industry E Rd. IV Science-Based Industrial Park,Hsinchu 300, Taiwan, R.O.C.
URLhttp://www.esmt.com.tw
