EDD5116ADTA-6B-E の詳細情報

  • 仕様・詳細
  • メーカー情報
型番EDD5116ADTA-6B-E
メーカーELPIDA
Access Mode FOUR BANK PAGE BURST
Access Time-Max 0.7 ns
Additional Feature AUTO/SELF REFRESH
Clock Frequency-Max (fCLK) 166 MHz
I/O Type COMMON
Interleaved Burst Length 2,4,8
JESD-30 Code R-PDSO-G66
JESD-609 Code e6
Length 22.22 mm
Memory Density 536870912 bit
Memory IC Type DDR1 DRAM
Memory Width 16
Number of Functions 1
Number of Ports 1
Number of Terminals 66
Number of Words 33554432 words
Number of Words Code 32M
Operating Mode SYNCHRONOUS
Operating Temperature-Max 70 Cel
Operating Temperature-Min 0 Cel
Organization 32MX16
Output Characteristics 3-STATE
Package Body Material PLASTIC/EPOXY
Package Code TSSOP
Package Equivalence Code TSSOP66,.46
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Power Supplies 2.5 V
Qualification Status Not Qualified
Refresh Cycles 8192
Seated Height-Max 1.2 mm
Self Refresh YES
Sequential Burst Length 2,4,8
Standby Current-Max 0.003 Amp
Sub Category DRAMs
Supply Current-Max 0.53 mA
Supply Voltage-Max (Vsup) 2.7 V
Supply Voltage-Min (Vsup) 2.3 V
Supply Voltage-Nom (Vsup) 2.5 V
Surface Mount YES
Technology CMOS
Temperature Grade COMMERCIAL
Terminal Finish TIN BISMUTH
Terminal Form GULL WING
Terminal Pitch 0.65 mm
Terminal Position DUAL
Width 10.16 mm
