ECS-327MV-CN-TR

Name: ECS-327MV-CN-TR
Brand: ECS
SKU: 400044558-0000-0000-0000

ECS-327MV-CN-TR - ECS の商品詳細ページです。

２営業日以内に回答いたします

ECS-327MV-CN-TR の詳細情報

型番	ECS-327MV-CN-TR
メーカー	ECS
Additional Feature	AT-CUT; STANDBY; ENABLE/DISABLE FUNCTION
Fall Time-Max	200 ns
Frequency Adjustment-Mechanical	NO
Frequency Stability	25 %
Mounting Feature	SURFACE MOUNT
Number of Terminals	4
Operating Frequency-Nom	0.032768 MHz
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Oscillator Type	CMOS
Output Load	15 pF
Package Body Material	CERAMIC
Package Equivalence Code	SOLCC4,.05,40
Physical Dimension	1.6mm x 1.2mm x 0.6mm
Rise Time-Max	200 ms
Supply Current-Max	0.03 mA
Supply Voltage-Max	3.63 V
Supply Voltage-Min	1.6 V
Symmetry-Max	45/55 %
