SUF4007

Name: SUF4007
Brand: DIOTEC
SKU: 290457994-0000-0000-0000

SUF4007 - DIOTEC の商品詳細ページです。

２営業日以内に回答いたします

SUF4007 の詳細情報

型番	SUF4007
メーカー	DIOTEC
Additional Feature	LOW POWER LOSS
Application	ULTRA FAST RECOVERY
Case Connection	ISOLATED
Configuration	SINGLE
Diode Element Material	SILICON
Diode Type	RECTIFIER DIODE
Forward Voltage-Max (VF)	1.7 V
JEDEC-95 Code	DO-204AL
JESD-30 Code	O-PALF-W2
JESD-609 Code	e2
Moisture Sensitivity Level	1
Non-rep Pk Forward Current-Max	30 A
Number of Elements	1
Number of Phases	1
Number of Terminals	2
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-50 Cel
Output Current-Max	1 A
Package Body Material	PLASTIC/EPOXY
Package Shape	ROUND
Package Style	LONG FORM Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Rep Pk Reverse Voltage-Max	1000 V
Reverse Current-Max	5 uA
Reverse Recovery Time-Max	0.075 us
Reverse Test Voltage	1000 V
Sub Category	Rectifier Diodes
Surface Mount	NO
Terminal Finish	TIN SILVER
Terminal Form	WIRE
Terminal Position	AXIAL
Time@Peak Reflow Temperature-Max (s)	10
