SBR15U30SP5-13
1
-
- 個
２営業日以内に回答いたします
SBR15U30SP5-13 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | SBR15U30SP5-13 |
|---|---|
| メーカー | DIODES |
| Application | GENERAL PURPOSE |
| Case Connection | CATHODE |
| Configuration | SINGLE |
| Diode Element Material | SILICON |
| Diode Type | RECTIFIER DIODE |
| Forward Voltage-Max (VF) | 0.42 V |
| JESD-30 Code | R-PDSO-F3 |
| JESD-609 Code | e3 |
| Moisture Sensitivity Level | 1 |
| Non-rep Pk Forward Current-Max | 250 A |
| Number of Elements | 1 |
| Number of Phases | 1 |
| Number of Terminals | 3 |
| Operating Temperature-Max | 150 Cel |
| Operating Temperature-Min | -65 Cel |
| Output Current-Max | 15 A |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Qualification Status | Not Qualified |
| Reference Standard | AEC-Q101 |
| Rep Pk Reverse Voltage-Max | 30 V |
| Reverse Current-Max | 500 uA |
| Sub Category | Rectifier Diodes |
| Surface Mount | YES |
| Technology | BLANK |
| Terminal Finish | MATTE TIN |
| Terminal Form | FLAT |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| 会社名称 | Diodes Incorporated |
|---|---|
| 所在地 | 4949 Hedgcoxe Road, Suite 200 Plano, TX 75024 United States |
| URL | http://www.diodes.com/ |
