DESD32VS2SO-7

Name: DESD32VS2SO-7
Brand: DIODES
SKU: 140198110-0000-0000-0000

DESD32VS2SO-7 - DIODES の商品詳細ページです。

２営業日以内に回答いたします

DESD32VS2SO-7 の詳細情報

型番	DESD32VS2SO-7
メーカー	DIODES
Breakdown Voltage-Max	40 V
Breakdown Voltage-Min	34 V
Configuration	COMMON ANODE, 2 ELEMENTS
Diode Element Material	SILICON
Diode Type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 Code	R-PDSO-G3
JESD-609 Code	e3
Moisture Sensitivity Level	1
Non-rep Peak Rev Power Dis-Max	200 W
Number of Elements	2
Number of Terminals	3
Operating Temperature-Max	150 Cel
Operating Temperature-Min	-65 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Polarity	UNIDIRECTIONAL
Power Dissipation-Max	0.3 W
Reference Standard	AEC-Q101
Rep Pk Reverse Voltage-Max	32 V
Surface Mount	YES
Technology	AVALANCHE
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30

会社名称	Diodes Incorporated
所在地	4949 Hedgcoxe Road, Suite 200 Plano, TX 75024 United States
URL	http://www.diodes.com/
