BAT54A-7-F データシート

Name: BAT54A-7-F
Brand: DIODES
SKU: 120011759-0000-0000-0000

BAT54A-7-F - DIODES の商品詳細ページです。

２営業日以内に回答いたします

BAT54A-7-F の詳細情報

型番	BAT54A-7-F
メーカー	DIODES
データシート
Additional Feature	HIGH RELIABILITY
Configuration	COMMON ANODE, 2 ELEMENTS
Diode Element Material	SILICON
Diode Type	RECTIFIER DIODE
Forward Voltage-Max (VF)	0.24 V
JESD-30 Code	R-PDSO-G3
JESD-609 Code	e3
Moisture Sensitivity Level	1
Non-rep Pk Forward Current-Max	0.6 A
Number of Elements	2
Number of Terminals	3
Operating Temperature-Max	150 Cel
Operating Temperature-Min	-65 Cel
Output Current-Max	0.1 A
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Power Dissipation-Max	0.2 W
Qualification Status	Not Qualified
Reference Standard	AEC-Q101
Rep Pk Reverse Voltage-Max	30 V
Reverse Recovery Time-Max	0.005 us
Sub Category	Rectifier Diodes
Surface Mount	YES
Technology	SCHOTTKY
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
