74LVC1G07Z-7
1
-
- 個
２営業日以内に回答いたします
74LVC1G07Z-7 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | 74LVC1G07Z-7 |
|---|---|
| メーカー | DIODES |
| DLA Qualification | Not Qualified |
| Family | LVC/LCX/Z |
| J-STD-609 Code | e3 |
| JESD-30 Code | R-PDSO-G5 |
| Length (mm) | 1.6 |
| Logic IC Type | BUFFER |
| Moisture Sensitivity Level | 1 |
| Number of Functions | 1 |
| Number of Inputs | 1 |
| Number of Terminals | 5 |
| Operating Temperature-Max (Cel) | 85 |
| Operating Temperature-Min (Cel) | -40 |
| Output Characteristics | OPEN-DRAIN |
| Output Low Current-Max (mA) | 24 |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | VSSOP |
| Package Equivalence Code | FL6,.047,20 |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH Meter |
| Packing Method | TR |
| Peak Reflow Temperature (Cel) | 260 |
| Power Supplies (V) | 3.3 |
| Propagation Delay (ns) | 8.5 |
| Schmitt Trigger | NO |
| Seated Height-Max (mm) | 0.62 |
| Sub Category | Gates |
| Supply Voltage-Max (V) | 5.5 |
| Supply Voltage-Min (V) | 1.65 |
| Supply Voltage-Nom (V) | 1.8 |
| Surface Mount | YES |
| Technology | CMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | MATTE TIN |
| Terminal Form | GULL WING |
| Terminal Pitch (mm) | 0.5 |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Width (mm) | 1.2 |
| 会社名称 | Diodes Incorporated |
|---|---|
| 所在地 | 4949 Hedgcoxe Road, Suite 200 Plano, TX 75024 United States |
| URL | http://www.diodes.com/ |
