DUSB-BRA42-T11(D4T) データシート

Name: DUSB-BRA42-T11(D4T)
Brand: DDK
SKU: 140184459-0000-0000-0000

DUSB-BRA42-T11(D4T) - DDK の商品詳細ページです。

２営業日以内に回答いたします

DUSB-BRA42-T11(D4T) の詳細情報

型番	DUSB-BRA42-T11(D4T)
メーカー	DDK
データシート
Additional Feature	ROHS COMPLIANT
Board Mounting Option	MOUNTING FLANGE
Body Breadth	0.437 inch
Body Depth	0.634 inch
Body Length	0.482 inch
Body/Shell Style	RECEPTACLE
Connector Type	USB CONNECTOR
Contact Finish - Mating	GOLD (30) OVER NICKEL
Contact Finish - Termination	TIN LEAD
Contact Gender	FEMALE
Contact Material	COPPER ALLOY
Contact Resistance	30 mohm
Contact Style	USB, SER B SQ
DIN Conformance	NO
Dielectric Withstanding Voltage	1050VAC V
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
Insulator Material	POLYAMIDE/POLYBUTYLENE TEREPHTHALATE
JESD-609 Code	e0
MIL Conformance	NO
Mixed Contacts	NO
Mounting Option 1	M3X0.5
Mounting Option 2	THREADED
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD AND PANEL
Number Of Connectors	ONE
Number Of PCB Rows	2
Number of Ports	1
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
PCB Contact Row Spacing	2.0066 mm
Plating Thickness	30u inch
Rated Current (Signal)	1 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Finish	TIN
Shell Material	COPPER ALLOY
Sub Category	Telecom and Datacom Connectors
Terminal Length	0.112 inch
Terminal Pitch	2.4892 mm
Termination Type	SOLDER
Total Number of Contacts	4
UL Flammability Code	94V-0
