57-40140R データシート

Name: 57-40140R
Brand: DDK
SKU: 60000045-0000-0000-0000

57-40140R - DDK の商品詳細ページです。

２営業日以内に回答いたします

57-40140R の詳細情報

型番	57-40140R
メーカー	DDK
データシート
Additional Feature	HIGH BARRIER TYPE
Body Breadth	0.63 inch
Body Length	1.728 inch
Body/Shell Style	PLUG
Contact Design	PREASSEM CONN
Contact Finish - Mating	AU
Contact Gender	FEMALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Style	BELLOWED TYPE
Dielectric Withstanding Voltage	1200VAC V
Insulation Resistance	1000000000 ohm
Insulator Material	DIALLYL PHTHALATE
Mounting Option 1	BAIL MT F
Mounting Type	CABLE
Number of Rows Loaded	2
Option	GENERAL PURPOSE
Rated Current (Signal)	5 A
Reference Standard	UL
Reliability	COMMERCIAL
Shell Finish	NICKEL
Shell Material	BRASS
Sub Category	D Type Connectors
Termination Type	WIRE
Total Number of Contacts	14
Wire Size-Max	22 AWG
Wire Size-Min	22 AWG
