57-30140 データシート

Name: 57-30140
Brand: DDK
SKU: 60163819-0000-0000-0000

57-30140 - DDK の商品詳細ページです。

２営業日以内に回答いたします

57-30140 の詳細情報

型番	57-30140
メーカー	DDK
データシート
Additional Feature	180 DEGREE TOP-ENTRY CABLE, BAIL LATCHES
Body Breadth	0.645 inch
Body Depth	0.843 inch
Body Length	1.417 inch
Body/Shell Style	PLUG
Connector Type	TELECOM AND DATACOM CONNECTOR
Contact Design	PREASSEM CONN
Contact Finish - Mating	AU
Contact Finish - Termination	GOLD (30) OVER NICKEL
Contact Gender	MALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Resistance	5 mohm
Contact Style	BELLOWED TYPE
DIN Conformance	NO
Dielectric Withstanding Voltage	700VDC V
Empty Shell	NO
Filter Feature	NO
IEC Conformance	NO
Insertion Force-Max	3.8086 N
Insulation Resistance	1000000000 ohm
Insulator Color	BLUE
Insulator Material	DIALLYL PHTHALATE
JESD-609 Code	e4
MIL Conformance	NO
Manufacturer Series	57
Mating Contact Pitch	0.085 inch
Mating Contact Row Spacing	0.1 inch
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Option 1	BAIL MT F
Mounting Option 2	SCREWLOCKS
Mounting Type	CABLE
Number of Rows Loaded	2
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
Plating Thickness	20u inch
Rated Current (Signal)	5 A
Reference Standard	CSA, UL
Reliability	COMMERCIAL
Shell Finish	NICKEL
Shell Material	BRASS
Sub Category	D Type Connectors
Termination Type	SOLDER
Total Number of Contacts	14
UL Flammability Code	94V-0
Wire Size-Max	22 AWG
Wire Size-Min	22 AWG
Withdrawl Force-Min	.6394 N
