DS1244Y

Name: DS1244Y
Brand: DALLAS
SKU: 140011941-0000-0000-0000

DS1244Y - DALLAS の商品詳細ページです。

２営業日以内に回答いたします

DS1244Y の詳細情報

型番	DS1244Y
メーカー	DALLAS
Additional Feature	ACCURACY 1 MIN/MONTH @ 25 DEGREE C; 10 YEARS DATA RETENTION; SERIAL 64-BIT PROTOCOL
External Data Bus Width	8
Information Access Method	PARALLEL
Interrupt Capability	N
JESD-30 Code	R-PDIP-P28
JESD-609 Code	e0
Length	25.019 mm
Moisture Sensitivity Level	1
Number of Terminals	28
Number of Timers	0
On Chip Data RAM Width	8
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP28,.6
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Power Supplies	5 V
Qualification Status	Not Qualified
RAM (words)	16384
Seated Height-Max	5.72 mm
Sub Category	Timer or RTC
Supply Current-Max	85 mA
Supply Voltage-Max	3.6 V
Supply Voltage-Min	3 V
Supply Voltage-Nom	3.3 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Finish	MATTE TIN
Terminal Form	J INVERTED
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time-Min	1/100 SECOND
Volatile	NO
Width	15.24 mm
uPs/uCs/Peripheral ICs Type	TIMER, REAL TIME CLOCK
