FM28V100-TG

Name: FM28V100-TG
Brand: CYPRESS
SKU: 160145459-0000-0000-0000

FM28V100-TG - CYPRESS の商品詳細ページです。

２営業日以内に回答いたします

FM28V100-TG の詳細情報

型番	FM28V100-TG
メーカー	CYPRESS
Access Time-Max	105 ns
Additional Feature	2kv ESD available
Data Retention Time-Min	10
Endurance	1.0E+14 Write/Erase Cycles
JESD-30 Code	R-PDSO-G32
Length	11.8 mm
Memory Density	1048576 bit
Memory IC Type	FRAM
Memory Width	8
Mfr Name	RAMTRON INTERNATIONAL CORP
Mfr P/N	FM28V100-TG
Moisture Sensitivity Level	3
New Category	FRAMs
New Part Type	MEMORY_ICS
Number of Functions	1
Number of Terminals	32
Number of Words	131072 words
Number of Words Code	128K
Old Category	Other Memory ICs
Old Part Type	MEMORY_ICS
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Organization	128KX8
Package Body Material	PLASTIC/EPOXY
Package Code	TSOP1
Package Equivalence Code	TSSOP32,.53,20
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE Meter
Parallel/Serial	PARALLEL
Part Objectid	2103867254
Peak Reflow Temperature (Cel)	260
Seated Height-Max	1.2 mm
Standby Current-Max	0.00015 Amp
Standby Voltage-Min	2 V
Supply Current-Max	0.012 mA
Supply Voltage-Max (Vsup)	3.6 V
Supply Voltage-Min (Vsup)	2 V
Supply Voltage-Nom (Vsup)	3.3 V
Surface Mount	YES
Technology	CMOS
Terminal Finish	PURE TIN
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Width	8 mm
