CY62128EV30LL-55SXE

Name: CY62128EV30LL-55SXE
Brand: CYPRESS
SKU: 130525322-0000-0000-0000

CY62128EV30LL-55SXE - CYPRESS の商品詳細ページです。

２営業日以内に回答いたします

CY62128EV30LL-55SXE の詳細情報

型番	CY62128EV30LL-55SXE
メーカー	CYPRESS
Access Time-Max	55 ns
I/O Type	COMMON
JESD-30 Code	R-PDSO-G32
JESD-609 Code	e4
Length	20.4465 mm
Memory Density	1048576 bit
Memory IC Type	STANDARD SRAM
Memory Width	8
Moisture Sensitivity Level	3
Number of Functions	1
Number of Ports	1
Number of Terminals	32
Number of Words	131072 words
Number of Words Code	128K
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Organization	128KX8
Output Characteristics	3-STATE
Output Enable	YES
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP32,.56
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Parallel/Serial	PARALLEL
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	2.997 mm
Standby Current-Max	3.0E-5 Amp
Standby Voltage-Min	1.5 V
Supply Current-Max	0.035 mA
Supply Voltage-Max (Vsup)	3.6 V
Supply Voltage-Min (Vsup)	2.2 V
Supply Voltage-Nom (Vsup)	3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	AUTOMOTIVE
Terminal Finish	NICKEL PALLADIUM GOLD
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	20
Width	11.303 mm
