CJ588821100 Cvilux

CJ588821100 - CVILUX の商品詳細ページです。

1
CJ588821100
  • CJ588821100
  • CJ588821100
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

CJ588821100 の詳細情報

  • 仕様・詳細
  • メーカー情報
型番CJ588821100
メーカーCVILUX
Additional Feature SHEILDED
Board Mounting Option PEG
Body Breadth 0.543 inch
Body Depth 0.838 inch
Body Length 0.63 inch
Body/Shell Style JACK
Connector Type TELECOM AND DATACOM CONNECTOR
Contact Gender FEMALE
Contact Pattern RECTANGULAR
Contact Resistance 20 mohm
Contact Style TELCOM, MODULAR
Dielectric Withstanding Voltage 1000VAC V
Empty Shell NO
Filter Feature NO
Insulation Resistance 500000000 ohm
Insulator Color BLACK
Insulator Material GLASS FILLED POLYESTER
Mixed Contacts NO
Mounting Option 1 LOCKING
Mounting Style RIGHT ANGLE
Mounting Type BOARD
Number Of PCB Rows 2
Number of Ports 1
Number of Rows Loaded 1
Operating Temperature-Max 105 Cel
Operating Temperature-Min -40 Cel
Option GENERAL PURPOSE
PCB Contact Pattern STAGGERED
PCB Contact Row Spacing 2.54 mm
Plating Thickness FLASH inch
Rated Current (Signal) 1.5 A
Reference Standard UL
Shell Finish TIN
Shell Material BRASS
Terminal Length 0.128 inch
Terminal Pitch 2.54 mm
Termination Type SOLDER
Total Number of Contacts 8
UL Flammability Code 94V-0
