SD-80BV
1
-
- 個
２営業日以内に回答いたします
SD-80BV の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | SD-80BV |
|---|---|
| メーカー | CUI |
| Body Depth | 0.62 inch |
| Connector Type | CIRCULAR DIN CONNECTOR |
| Contact Finish - Mating | AG |
| Contact Material | BRASS |
| Contact Resistance | 30 mohm |
| DIN Conformance | YES |
| Dielectric Withstanding Voltage | 500VAC V |
| Durability | 500 Cycles |
| Insulation Resistance | 100000000 ohm |
| Mounting Option 1 | LOCKING |
| Mounting Style | STRAIGHT |
| Mounting Type | BOARD |
| Number of Ports | 1 |
| Operating Temperature-Max | 60 Cel |
| Operating Temperature-Min | -20 Cel |
| Polarization Key | POLAR PIN POSITION |
| Rated Current (Signal) | 1 A |
| Reliability | COMMERCIAL |
| Shell Finish | NICKEL |
| Shell Material | IRON |
| Sub Category | DIN Connectors |
| Terminal Length | 0.16 inch |
| Termination Type | SOLDER |
| Total Number of Contacts | 8 |
| 会社名称 | CUI Inc |
|---|---|
| 設立 | 1989 |
| 所在地 | 20050 SW 112th Avenue Tualatin, OR 97062, USA |
| URL | http://www.cui.com/ |
