ZUS102412 データシート

Name: ZUS102412
Brand: COSEL
SKU: 360002699-0000-0000-0000

ZUS102412 - COSEL の商品詳細ページです。

２営業日以内に回答いたします

ZUS102412 の詳細情報

型番	ZUS102412
メーカー	COSEL
データシート
Analog IC - Other Type	DC-DC REGULATED POWER SUPPLY MODULE
Input Voltage-Max	36 V
Input Voltage-Min	18 V
Input Voltage-Nom	24 V
JESD-30 Code	R-XDMA-P4
Length	45 mm
Number of Functions	1
Number of Outputs	1
Number of Terminals	4
Operating Temperature-Max	55 Cel
Operating Temperature-Min	-20 Cel
Output Current-Max	0.9 A
Output Voltage-Max	12.6 V
Output Voltage-Min	11.4 V
Output Voltage-Nom	12 V
Package Body Material	UNSPECIFIED
Package Equivalence Code	MODULE,4LEAD,1.6
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Seated Height-Max	7.3 mm
Sub Category	Other Analog ICs
Surface Mount	NO
Technology	HYBRID
Temperature Grade	OTHER
Terminal Form	PIN/PEG
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	10.8 W
Trim/Adjustable Output	NO V
Width	35 mm
