SUW102415B データシート

Name: SUW102415B
Brand: COSEL
SKU: 290469727-0000-0000-0000

SUW102415B - COSEL の商品詳細ページです。

２営業日以内に回答いたします

SUW102415B の詳細情報

型番	SUW102415B
メーカー	COSEL
データシート
Additional Feature	ADDITIONAL -15V OUTPUT OR 30V OUTPUT ALSO AVAILABLE
Analog IC - Other Type	DC-DC REGULATED POWER SUPPLY MODULE
Approvals	CE, TUV, UL V
Efficiency (Main Output)	86 %
Height	6.5 mm
Input Voltage-Max	36 V
Input Voltage-Min	18 V
Input Voltage-Nom	24 V
JESD-30 Code	R-XDMA-G7
Length	39.2 mm
Number of Functions	1
Number of Outputs	2
Number of Terminals	7
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	0.35 A
Output Voltage-Max	15.75 V
Output Voltage-Min	14.25 V
Output Voltage-Nom	15 V
Package Body Material	UNSPECIFIED
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Seated Height-Max	7 mm
Sub Category	Power Supply Modules
Surface Mount	YES
Technology	HYBRID
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	10.5 W
Trim/Adjustable Output	YES V
Width	21 mm
