SUS1R50515C データシート

Name: SUS1R50515C
Brand: COSEL
SKU: 290413036-0000-0000-0000

SUS1R50515C - COSEL の商品詳細ページです。

２営業日以内に回答いたします

SUS1R50515C の詳細情報

型番	SUS1R50515C
メーカー	COSEL
データシート
Analog IC - Other Type	DC-DC REGULATED POWER SUPPLY MODULE
Input Voltage-Max	9 V
Input Voltage-Min	4.5 V
Input Voltage-Nom	5 V
JESD-30 Code	R-XDMA-T5
Length	21.4 mm
Number of Functions	1
Number of Outputs	1
Number of Terminals	5
Output Voltage-Max	15.75 V
Output Voltage-Min	14.25 V
Output Voltage-Nom	15 V
Package Body Material	UNSPECIFIED
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Seated Height-Max	7 mm
Surface Mount	NO
Technology	HYBRID
Terminal Form	THROUGH-HOLE
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	1.5 W
Trim/Adjustable Output	YES V
Width	12.2 mm
