SUCW1R52415C データシート

Name: SUCW1R52415C
Brand: COSEL
SKU: 290459299-0000-0000-0000

SUCW1R52415C - COSEL の商品詳細ページです。

２営業日以内に回答いたします

SUCW1R52415C の詳細情報

型番	SUCW1R52415C
メーカー	COSEL
データシート
Additional Feature	ADDITIONAL -15V OUTPUT AVAILABLE, 30V OUTPUT IS AVAILABLE WHEN PINS ARE SHORTED
Analog IC - Other Type	DC-DC REGULATED POWER SUPPLY MODULE
Input Voltage-Max	36 V
Input Voltage-Min	18 V
Input Voltage-Nom	24 V
JESD-30 Code	R-XDMA-T6
Length	22.4 mm
Number of Functions	1
Number of Outputs	2
Number of Terminals	6
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	0.05 A
Output Voltage-Max	15.75 V
Output Voltage-Min	14.25 V
Output Voltage-Nom	15 V
Package Body Material	PLASTIC/EPOXY
Package Equivalence Code	MODULE(UNSPEC)
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Qualification Status	Not Qualified
Seated Height-Max	7.5 mm
Sub Category	Other Analog ICs
Surface Mount	NO
Technology	HYBRID
Temperature Grade	INDUSTRIAL
Terminal Form	THROUGH-HOLE
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	1.5 W
Trim/Adjustable Output	YES V
Width	12.7 mm
