SFS304805B データシート

Name: SFS304805B
Brand: COSEL
SKU: 290465938-0000-0000-0000

SFS304805B - COSEL の商品詳細ページです。

２営業日以内に回答いたします

SFS304805B の詳細情報

型番	SFS304805B
メーカー	COSEL
データシート
Additional Feature	REMOTE SHUTDOWN
Analog IC - Other Type	DC-DC REGULATED POWER SUPPLY MODULE
Approvals	CE, TUV, UL V
Efficiency (Main Output)	92.5 %
Height	8 mm
Input Voltage-Max	76 V
Input Voltage-Min	36 V
Input Voltage-Nom	48 V
JESD-30 Code	R-XDMA-G17
Length	38.7 mm
Number of Functions	1
Number of Outputs	1
Number of Terminals	17
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	6 A
Output Voltage-Max	5.25 V
Output Voltage-Min	4.85 V
Output Voltage-Nom	5 V
Package Body Material	UNSPECIFIED
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Seated Height-Max	8 mm
Sub Category	Power Supply Modules
Surface Mount	YES
Technology	HYBRID
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	30 W
Trim/Adjustable Output	NO V
Width	31.2 mm
