PBA50F-15 データシート

Name: PBA50F-15
Brand: COSEL
SKU: 260104389-0000-0000-0000

PBA50F-15 - COSEL の商品詳細ページです。

２営業日以内に回答いたします

PBA50F-15 の詳細情報

型番	PBA50F-15
メーカー	COSEL
データシート
Additional Feature	REMOTE SHUTDOWN
Analog IC - Other Type	AC-DC POWER FACTOR CORRECTION MODULE
Approvals	CE, EN, TUV, UL V
Efficiency (Main Output)	83 %
Height	82 mm
Input Voltage-Max	240 V
Input Voltage-Min	85 V
Length	120 mm
Operating Temperature-Max	71 Cel
Operating Temperature-Min	-10 Cel
Output Current-Max	3.5 A
Output Voltage-Nom	15 V
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Protection(s)	OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE V
Ripple Voltage (Main Out)	0.04242 Vrms
Sub Category	Power Supply Modules
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	52.5 W
Width	31 mm
