PBA300F-12 データシート

Name: PBA300F-12
Brand: COSEL
SKU: 260076364-0000-0000-0000

PBA300F-12 - COSEL の商品詳細ページです。

２営業日以内に回答いたします

PBA300F-12 の詳細情報

型番	PBA300F-12
メーカー	COSEL
データシート
Additional Feature	REMOTE SHUTDOWN
Analog IC - Other Type	AC-DC POWER FACTOR CORRECTION MODULE
Approvals	CE, TUV, UL V
Efficiency (Main Output)	78 %
Height	42 mm
Input Voltage-Max	264 V
Input Voltage-Min	85 V
Length	170 mm
Operating Temperature-Max	71 Cel
Operating Temperature-Min	-20 Cel
Output Current-Max	27 A
Output Voltage-Nom	12 V
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Protection(s)	OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE V
Sub Category	Power Supply Modules
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	324 W
Width	102 mm
