PBA10F-5-J

Name: PBA10F-5-J
Brand: COSEL
SKU: 400067207-0000-0000-0000

PBA10F-5-J - COSEL の商品詳細ページです。

２営業日以内に回答いたします

PBA10F-5-J の詳細情報

型番	PBA10F-5-J
メーカー	COSEL
Additional Feature	ALSO OPERATE WITH 110V TO 370VDC
Analog IC - Other Type	AC-DC POWER FACTOR CORRECTION MODULE
Approvals	C-UL, UL, EN V
Efficiency (Main Output)	74 %
Input Voltage-Max	264 V
Input Voltage-Min	85 V
Input Voltage-Nom	100 V
JESD-30 Code	R-XXMA-X
Line Regulation-Max	0.001 %
Load Regulation-Max	0.8 %
Number of Functions	1
Number of Outputs	1
Operating Temperature-Max	71 Cel
Operating Temperature-Min	-10 Cel
Output Current-Max	2 A
Output Voltage-Max	5.15 V
Output Voltage-Min	5 V
Output Voltage-Nom	5 V
Package Body Material	UNSPECIFIED
Package Code	XMA
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Protection(s)	OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE V
Ripple Voltage (Main Out)	0.05656 Vrms
Surface Mount	NO
Technology	HYBRID
Terminal Form	UNSPECIFIED
Terminal Position	UNSPECIFIED
Total Power Output-Max	10 W
Trim/Adjustable Output	NO V
Warm-Up Time	0.2 Seconds
