LFA10F-12-SNJ1 データシート

Name: LFA10F-12-SNJ1
Brand: COSEL
SKU: 400059825-0000-0000-0000

LFA10F-12-SNJ1 - COSEL の商品詳細ページです。

２営業日以内に回答いたします

LFA10F-12-SNJ1 の詳細情報

型番	LFA10F-12-SNJ1
メーカー	COSEL
データシート
Analog IC - Other Type	AC-DC REGULATED POWER SUPPLY MODULE
Approvals	CUL, UL, CE, EN V
Efficiency (Main Output)	79 %
Input Voltage-Max	264 V
Input Voltage-Min	85 V
Input Voltage-Nom	100 V
JESD-30 Code	R-XXFM-X
Length	93.5 mm
Line Regulation-Max	0.00576 %
Load Regulation-Max	0.83333 %
Number of Functions	1
Number of Outputs	1
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-10 Cel
Output Current-Max	0.9 A
Output Voltage-Max	12.5 V
Output Voltage-Min	10.8 V
Output Voltage-Nom	12 V
Package Body Material	UNSPECIFIED
Package Code	XFM
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Protection(s)	OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE V
Ripple Voltage (Main Out)	0.10605 Vrms
Surface Mount	NO
Technology	HYBRID
Terminal Form	UNSPECIFIED
Terminal Position	UNSPECIFIED
Total Power Output-Max	10.8 W
Trim/Adjustable Output	NO V
Warm-Up Time	0.2 Seconds
Width	60 mm
