LEP150F-36 データシート

Name: LEP150F-36
Brand: COSEL
SKU: 220181478-0000-0000-0000

LEP150F-36 - COSEL の商品詳細ページです。

２営業日以内に回答いたします

LEP150F-36 の詳細情報

型番	LEP150F-36
メーカー	COSEL
データシート
Analog IC - Other Type	AC-DC REGULATED POWER SUPPLY MODULE
Approvals	UL, CUL, EN, IEC V
Efficiency (Main Output)	86 %
Input Voltage-Max	264 V
Input Voltage-Min	85 V
Input Voltage-Nom	100 V
JESD-30 Code	R-XXFM-X
Length	222 mm
Line Regulation-Max	0.01728 %
Load Regulation-Max	0.25 %
Number of Functions	1
Number of Outputs	1
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-10 Cel
Output Current-Max	4.2 A
Output Voltage-Max	39.6 V
Output Voltage-Min	26.4 V
Output Voltage-Nom	36 V
Package Body Material	UNSPECIFIED
Package Code	XFM
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Protection(s)	OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE V
Ripple Voltage (Main Out)	0.04242 Vrms
Surface Mount	NO
Technology	HYBRID
Terminal Form	UNSPECIFIED
Terminal Position	UNSPECIFIED
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	151.2 W
Trim/Adjustable Output	YES V
Warm-Up Time	0.5 Seconds
Width	85 mm
