LDA50F-12 データシート

Name: LDA50F-12
Brand: COSEL
SKU: 220171004-0000-0000-0000

LDA50F-12 - COSEL の商品詳細ページです。

２営業日以内に回答いたします

LDA50F-12 の詳細情報

型番	LDA50F-12
メーカー	COSEL
データシート
Additional Feature	REMOTE SHUTDOWN
Analog IC - Other Type	AC-DC REGULATED POWER SUPPLY MODULE
Approvals	CE, CSA, EN, TUV, UL V
Efficiency (Main Output)	80 %
Height	23 mm
Input Voltage-Max	264 V
Input Voltage-Min	85 V
Input Voltage-Nom	100 V
JESD-30 Code	R-XXMA-X10
Length	195 mm
Number of Functions	1
Number of Outputs	1
Number of Terminals	10
Operating Temperature-Max	60 Cel
Operating Temperature-Min	-10 Cel
Output Current-Max	4.3 A
Output Voltage-Max	13.2 V
Output Voltage-Min	10.8 V
Output Voltage-Nom	12 V
Package Body Material	UNSPECIFIED
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Protection(s)	OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE V
Ripple Voltage (Main Out)	0.04242 Vrms
Sub Category	Power Supply Modules
Surface Mount	NO
Technology	HYBRID
Temperature Grade	COMMERCIAL
Terminal Form	UNSPECIFIED
Terminal Position	UNSPECIFIED
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	51.6 W
Trim/Adjustable Output	YES V
Warm-Up Time	0.2 Seconds
Width	36 mm
