LDA300W-30 の詳細情報

型番	LDA300W-30
メーカー	COSEL
データシート
Additional Feature	IT ALSO OPERATES WITH 170VAC TO 264VAC INPUT VOLTAGE
Analog IC - Other Type	AC-DC REGULATED POWER SUPPLY MODULE
Approvals	UL, CUL, EN, IEC V
Efficiency (Main Output)	86 %
Input Voltage-Max	132 V
Input Voltage-Min	85 V
Input Voltage-Nom	100 V
JESD-30 Code	R-XXFM-X
Line Regulation-Max	0.036 %
Load Regulation-Max	0.6 %
Number of Functions	1
Number of Outputs	1
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-10 Cel
Output Current-Max	7 A
Output Voltage-Max	33 V
Output Voltage-Min	27 V
Output Voltage-Nom	30 V
Package Body Material	UNSPECIFIED
Package Code	XFM
Package Shape	RECTANGULAR
Package Style	FLANGE MOUNT Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Protection(s)	OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE V
Ripple Voltage (Main Out)	0.06363 Vrms
Surface Mount	NO
Technology	HYBRID
Terminal Form	UNSPECIFIED
Terminal Position	UNSPECIFIED
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Total Power Output-Max	300 W
Trim/Adjustable Output	YES V
Warm-Up Time	0.2 Seconds
