RFC1010B-156KE
1
-
- 個
２営業日以内に回答いたします
RFC1010B-156KE の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | RFC1010B-156KE |
|---|---|
| メーカー | COILCRAFT |
| Construction | Flame Retardant |
| Core Material | Ferrite |
| DC Resistance | 19.5 ohm |
| Inductance-Nom (L) | 15000 uH |
| Inductor Application | POWER INDUCTOR |
| Inductor Type | GENERAL PURPOSE INDUCTOR |
| Lead Diameter | 0.8 mm |
| Lead Length | 5 mm |
| Lead Spacing | 6 mm |
| Number of Functions | 1 |
| Number of Terminals | 2 |
| Operating Temperature-Max | 85 Cel |
| Operating Temperature-Min | -40 Cel |
| Package Diameter | 11 mm |
| Package Length | 11.5 mm |
| Package Style | Radial Meter |
| Packing Method | Tray |
| Rated Current-Max | 0.17 A |
| Reference Standard | AEC-Q200 |
| Self Resonance Frequency | 0.38 MHz |
| Shape/Size Description | CYLINDRICAL PACKAGE |
| Shielded | NO |
| Surface Mount | NO |
| Terminal Finish | Tin/Silver - Matte Tin - with Nickel barrier |
| Terminal Placement | RADIAL |
| Terminal Shape | WIRE |
| Test Frequency | 0.1 MHz |
| Tolerance | 10 % |
| 会社名称 | Coilcraft, Inc. |
|---|---|
| 設立 | 1945 |
| 所在地 | 1102 Silver Lake Road,Cary IL 60013 United States |
| URL | URL:http://www.coilcraft.com/ |
