131-3701-811
1
-
- 個
２営業日以内に回答いたします
131-3701-811 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | 131-3701-811 |
|---|---|
| メーカー | CINCH |
| Additional Feature | INSERTION LOSS AT 1.5GHZ |
| Body Breadth | 0.312 inch |
| Body Depth | 0.562 inch |
| Body Length | 0.375 inch |
| Body/Shell Style | JACK |
| Characteristic Impedance | 50 ohm |
| Connector Type | RF SMB CONNECTOR |
| Contact Finish - Mating | GOLD |
| Contact Finish - Termination | GOLD |
| Contact Gender | MALE |
| Contact Material | NOT SPECIFIED |
| Contact Resistance | 8 mohm |
| Contact Style | COAX |
| Coupling Type | SNAP |
| DIN Conformance | NO |
| Dielectric Withstanding Voltage | 1400VAC V |
| Durability | 500 Cycles |
| Filter Feature | NO |
| IEC Conformance | NO |
| Insertion Loss | 0.3 dB |
| Insulation Resistance | 1000000000 ohm |
| Insulator Material | PERFLUOROALKOXY/POLYTETRAFLUOROETHYLENE |
| JESD-609 Code | e4 |
| MIL Conformance | NO |
| Manufacturer Series | 131 |
| Mounting Option 1 | LOCKING |
| Mounting Style | RIGHT ANGLE |
| Mounting Type | BOARD |
| Number of Ports | 1 |
| Operating Frequency-Max | 4 GHz |
| Operating Temperature-Max | 165 Cel |
| Operating Temperature-Min | -65 Cel |
| Option | GENERAL PURPOSE |
| Panel Mount | NO |
| Reliability | COMMERCIAL |
| Shell Material | BRASS |
| Sub Category | RF SMB/SSMB Connectors |
| Termination Type | SURFACE MOUNT |
| Total Number of Contacts | 1 |
