CS16LV81923BGCR55

Name: CS16LV81923BGCR55
Brand: CHIPLUS
SKU: 130589388-0000-0000-0000

CS16LV81923BGCR55 - CHIPLUS の商品詳細ページです。

２営業日以内に回答いたします

CS16LV81923BGCR55 の詳細情報

型番	CS16LV81923BGCR55
メーカー	CHIPLUS
Access Time-Max	55 ns
JESD-30 Code	R-PDSO-G44
Length	18.41 mm
Memory Density	8388608 bit
Memory IC Type	STANDARD SRAM
Memory Width	16
Number of Functions	1
Number of Terminals	44
Number of Words	524288 words
Number of Words Code	512K
Operating Mode	ASYNCHRONOUS
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Organization	512KX16
Package Body Material	PLASTIC/EPOXY
Package Code	TSOP2
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE Meter
Parallel/Serial	PARALLEL
Seated Height-Max	1.2 mm
Supply Voltage-Max (Vsup)	3.6 V
Supply Voltage-Min (Vsup)	2.7 V
Supply Voltage-Nom (Vsup)	3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Form	GULL WING
Terminal Pitch	0.8 mm
Terminal Position	DUAL
Width	10.16 mm

会社名称	Chiplus Semiconductor Corp.
設立	2002
所在地	4F, No 15, Industry East Rd. 9, Science-Based Industrial Park, Hsinchu, Taiwan 300, R.O.C
URL	http://www.chiplus.com/
