OPA445BM データシート Burrbrown

OPA445BM - BURR-BROWN の商品詳細ページです。

1
OPA445BM
  • OPA445BM
  • OPA445BM
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

OPA445BM の詳細情報

  • 仕様・詳細
  • メーカー情報
型番OPA445BM
メーカーBURR-BROWN
データシートProduct_list_pdf
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB) 5.0E-5 uA
Bias Current-Max (IIB) @25C 5.0E-5 uA
Common-mode Reject Ratio-Min 80 dB
Common-mode Reject Ratio-Nom 95 dB
Frequency Compensation YES
Input Offset Current-Max (IIO) 0.005 uA
Input Offset Voltage-Max 3000 uV
JESD-30 Code O-MBCY-T8
JESD-609 Code e0
Length 9.08 mm
Low-Bias YES
Low-Offset NO
Micropower NO
Neg Supply Voltage Limit-Max -50 V
Neg Supply Voltage-Nom (Vsup) -40 V
Number of Functions 1
Number of Terminals 8
Operating Temperature-Max 85 Cel
Operating Temperature-Min -25 Cel
Package Body Material METAL
Package Code TO-99
Package Equivalence Code CAN8,.2
Package Shape ROUND
Package Style CYLINDRICAL Meter
Packing Method TUBE
Power NO
Power Supplies +-40 V
Programmable Power NO
Qualification Status Not Qualified
Seated Height-Max 5.72 mm
Slew Rate-Min 5 V/us
Slew Rate-Nom 10 V/us
Sub Category Operational Amplifier
Supply Current-Max 4.5 mA
Supply Voltage Limit-Max 50 V
Supply Voltage-Nom (Vsup) 40 V
Surface Mount NO
Technology BIPOLAR
Temperature Grade OTHER
Terminal Finish GOLD
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position BOTTOM
Unity Gain BW-Nom 2000 kHz
Voltage Gain-Min 70794.6
Wideband NO
Width 9.08 mm
会社名称Texas Instruments
設立1930
資本金USD 13.7 billion
所在地12500 TI Boulevard Dallas, Texas 75243 United States
URLhttp://www.burr-brown.com/

OPA445BMのレビュー

OPA445BM のご注文について
