ADS7805P の詳細情報

  • 仕様・詳細
  • メーカー情報
型番ADS7805P
メーカーBURR-BROWN
データシートProduct_list_pdf
Analog Input Voltage-Max 10 V
Analog Input Voltage-Min -10 V
Conversion Time-Max 8 us
Converter Type ADC, SUCCESSIVE APPROXIMATION
JESD-30 Code R-PDIP-T28
JESD-609 Code e0
Length 35.69 mm
Linearity Error-Max (EL) 0.0046 %
Number of Analog In Channels 1
Number of Bits 16
Number of Functions 1
Number of Terminals 28
Operating Temperature-Max 85 Cel
Operating Temperature-Min -25 Cel
Output Bit Code 2'S COMPLEMENT BINARY
Output Format PARALLEL, WORD
Package Body Material PLASTIC/EPOXY
Package Code DIP
Package Equivalence Code DIP28,.3
Package Shape RECTANGULAR
Package Style IN-LINE Meter
Power Supplies 5 V
Qualification Status Not Qualified
Sample Rate 0.1 MHz
Sample-and-Hold/Track-and-Hold SAMPLE
Seated Height-Max 5.08 mm
Sub Category Analog to Digital Converters
Supply Voltage-Nom 5 V
Surface Mount NO
Technology CMOS
Temperature Grade OTHER
Terminal Finish NICKEL PALLADIUM GOLD
Terminal Form THROUGH-HOLE
Terminal Pitch 2.54 mm
Terminal Position DUAL
Width 7.62 mm
