CDSOT23-SRV05-4
1
-
- 個
２営業日以内に回答いたします
CDSOT23-SRV05-4 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | CDSOT23-SRV05-4 |
|---|---|
| メーカー | BOURNS |
| Additional Feature | LOW CAPACITANCE |
| Breakdown Voltage-Min | 6 V |
| Breakdown Voltage-Nom | 6 V |
| Clamping Voltage-Max | 15 V |
| Configuration | SINGLE |
| Diode Element Material | SILICON |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE |
| JESD-30 Code | R-PDSO-G6 |
| JESD-609 Code | e4 |
| Moisture Sensitivity Level | 1 |
| Non-rep Peak Rev Power Dis-Max | 500 W |
| Number of Elements | 1 |
| Number of Terminals | 6 |
| Operating Temperature-Max | 150 Cel |
| Operating Temperature-Min | -55 Cel |
| Package Body Material | PLASTIC/EPOXY |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE Meter |
| Peak Reflow Temperature (Cel) | 260 |
| Polarity | UNIDIRECTIONAL |
| Qualification Status | Not Qualified |
| Rep Pk Reverse Voltage-Max | 5 V |
| Sub Category | Transient Suppressors |
| Surface Mount | YES |
| Technology | AVALANCHE |
| Terminal Finish | NICKEL PALLADIUM GOLD |
| Terminal Form | GULL WING |
| Terminal Position | DUAL |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| 会社名称 | Bourns, Inc. |
|---|---|
| 設立 | 1947 |
| 所在地 | 1200 Columbia Ave. Riverside, CA 92507-2129, United States |
| URL | http://www.bourns.com/ |
