698-3-R10KBLF データシート

Name: 698-3-R10KBLF
Brand: BI TECH
SKU: 70005078-0000-0000-0000

698-3-R10KBLF - BI TECH の商品詳細ページです。

２営業日以内に回答いたします

698-3-R10KBLF の詳細情報

型番	698-3-R10KBLF
メーカー	BI TECH
データシート
Additional Feature	PRECISION
Construction	Molded
Element Power Dissipation	0.1 W
First Element Resistance	10000 ohm
JESD-609 Code	e3
Lead Length	4 mm
Lead Spacing	2.54 mm
Mounting Feature	THROUGH HOLE MOUNT
Network Type	ISOLATED
Number of Elements	1
Number of Functions	8
Number of Terminals	16
Operating Temperature-Max	150 Cel
Operating Temperature-Min	-55 Cel
Package Height	4 mm
Package Length	19.05 mm
Package Shape	RECTANGULAR PACKAGE
Package Style	DIP Meter
Package Width	6.35 mm
Packing Method	TUBE
Rated Power Dissipation (P)	0.6 W
Rated Temperature	70 Cel
Resistance	10000 ohm
Resistor Type	ARRAY/NETWORK RESISTOR
Size Code	7525
Sub Category	Array/Network Resistors
Technology	THIN FILM
Temperature Coefficient	25 ppm/Cel
Temperature Coefficient Tracking	5 ppm/Cel
Terminal Finish	Matte Tin (Sn)
Terminal Shape	FLAT
Tolerance	0.1 %
Working Voltage	100 V
