BSV-1.8S5R0DLA データシート

Name: BSV-1.8S5R0DLA
Brand: BELLNIX
SKU: 120174258-0000-0000-0000

BSV-1.8S5R0DLA - BELLNIX の商品詳細ページです。

２営業日以内に回答いたします

BSV-1.8S5R0DLA の詳細情報

型番	BSV-1.8S5R0DLA
メーカー	BELLNIX
データシート
Analog IC - Other Type	DC-DC REGULATED POWER SUPPLY MODULE
Input Voltage-Max	5.5 V
Input Voltage-Min	3 V
Input Voltage-Nom	4.5 V
JESD-30 Code	R-XDMA-T12
Length	25.4 mm
Load Regulation-Max	2 %
Number of Functions	1
Number of Outputs	1
Number of Terminals	12
Operating Temperature-Max	40 Cel
Operating Temperature-Min	-40 Cel
Output Voltage-Max	3.3 V
Output Voltage-Min	1 V
Output Voltage-Nom	1.8 V
Package Body Material	UNSPECIFIED
Package Shape	RECTANGULAR
Package Style	MICROELECTRONIC ASSEMBLY Meter
Seated Height-Max	6.5 mm
Surface Mount	NO
Technology	HYBRID
Temperature Grade	OTHER
Terminal Form	THROUGH-HOLE
Terminal Position	DUAL
Total Power Output-Max	9 W
Trim/Adjustable Output	YES V
Width	22.25 mm
