F931C107MCCAJ6
1
-
- 個
２営業日以内に回答いたします
F931C107MCCAJ6 の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | F931C107MCCAJ6 |
|---|---|
| メーカー | AVX |
| Additional Feature | ESR AND RIPPLE CURRENT IS MEASURED AT 100KHZ |
| Capacitance | 100 uF |
| Capacitor Type | TANTALUM CAPACITOR |
| Dielectric Material | TANTALUM (DRY/SOLID) |
| ESR | 700 mohm |
| Height | 2.6 mm |
| Leakage Current | 0.016 mA |
| Length | 6 mm |
| Mounting Feature | SURFACE MOUNT |
| Negative Tolerance | 20 % |
| Number of Terminals | 2 |
| Operating Temperature-Max | 125 Cel |
| Operating Temperature-Min | -55 Cel |
| Package Style | SMT Meter |
| Packing Method | TR, 7 INCH |
| Polarity | POLARIZED |
| Positive Tolerance | 20 % |
| Rated DC Voltage (URdc) | 16 V |
| Reference Standard | AEC-Q200 |
| Ripple Current | 159 mA |
| Size Code | 2312 |
| Tan Delta | 0.15 |
| Terminal Shape | J BEND |
| Width | 3.2 mm |
| 会社名称 | AVX Corporate |
|---|---|
| 所在地 | Fountain Inn, SC 29644-9039 United States |
| URL | http://www.avx.com/ |
