F931A337MNC
1
-
- 個
２営業日以内に回答いたします
F931A337MNC の詳細情報
- 仕様・詳細
- メーカー情報
| 型番 | F931A337MNC |
|---|---|
| メーカー | AVX |
| Additional Feature | ESR AND RIPPLE CURRENT IS MEASURED AT 100KHZ |
| Capacitance | 330 uF |
| Capacitor Type | TANTALUM CAPACITOR |
| Dielectric Material | TANTALUM (DRY/SOLID) |
| ESR | 500 mohm |
| Height | 2.8 mm |
| JESD-609 Code | e3 |
| Leakage Current | .033 mA |
| Length | 7.3 mm |
| Mounting Feature | SURFACE MOUNT |
| Negative Tolerance | 20 % |
| Number of Terminals | 2 |
| Operating Temperature-Max | 125 Cel |
| Operating Temperature-Min | -55 Cel |
| Package Shape | RECTANGULAR PACKAGE |
| Package Style | SMT Meter |
| Packing Method | TR, 7 INCH |
| Polarity | POLARIZED |
| Positive Tolerance | 20 % |
| Rated DC Voltage (URdc) | 10 V |
| Reference Standard | AEC-Q200 |
| Ripple Current | 219 mA |
| Size Code | 2917 |
| Tan Delta | 0.18 |
| Terminal Finish | Matte Tin (Sn) - with Nickel (Ni) barrier |
| Terminal Shape | J BEND |
| Width | 4.3 mm |
| 会社名称 | AVX Corporate |
|---|---|
| 所在地 | Fountain Inn, SC 29644-9039 United States |
| URL | http://www.avx.com/ |
