ATMEGA8515-16MI データシート

Name: ATMEGA8515-16MI
Brand: ATMEL
SKU: 110056560-0000-0000-0000

ATMEGA8515-16MI - ATMEL の商品詳細ページです。

２営業日以内に回答いたします

ATMEGA8515-16MI の詳細情報

型番	ATMEGA8515-16MI
メーカー	ATMEL
データシート
ADC Channels	NO
Address Bus Width	16
Bit Size	8
CPU Family	AVR RISC
Clock Frequency-Max	16 MHz
DAC Channels	NO
DMA Channels	NO
External Data Bus Width	8
JESD-30 Code	S-PQCC-N44
JESD-609 Code	e0
Length	7 mm
Number of I/O Lines	35
Number of Terminals	44
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
PWM Channels	YES
Package Body Material	PLASTIC/EPOXY
Package Code	HVQCCN
Package Equivalence Code	LCC44,.28SQ,20
Package Shape	SQUARE
Package Style	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Power Supplies	5 V
Qualification Status	Not Qualified
RAM (bytes)	512
ROM (words)	4096
ROM Programmability	FLASH
Seated Height-Max	1 mm
Speed	16 rpm
Sub Category	Microcontrollers
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN LEAD
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Width	7 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
