AT89S51-24JU の詳細情報

  • 仕様・詳細
  • メーカー情報
型番AT89S51-24JU
メーカーATMEL
データシートProduct_list_pdf
ADC Channels NO
Address Bus Width 16
Bit Size 8
Boundary Scan NO
CPU Family 80C51
Clock Frequency-Max 33 MHz
Connectivity UART
DAC Channels NO
DMA Channels NO
Data EEPROM Size 0
External Data Bus Width 8
Format FIXED POINT
JESD-30 Code S-PQCC-J44
JESD-609 Code e3
Length 16.586 mm
Moisture Sensitivity Level 2
Number of I/O Lines 32
Number of Terminals 44
On Chip Program ROM Width 8
Operating Temperature-Max 85 Cel
Operating Temperature-Min -40 Cel
PWM Channels NO
Package Body Material PLASTIC/EPOXY
Package Code HQCCJ
Package Equivalence Code LCC44,.65SQ
Package Shape SQUARE
Package Style CHIP CARRIER Meter
Peak Reflow Temperature (Cel) 245
Peripherals TIMER(2), WDT
Power Supplies 5 V
Qualification Status Not Qualified
RAM (bytes) 128
ROM (words) 4096
ROM Programmability FLASH
Seated Height-Max 4.572 mm
Speed 24 rpm
Sub Category Microcontrollers
Supply Current-Max 25 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 4 V
Supply Voltage-Nom 5 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish MATTE TIN
Terminal Form J BEND
Terminal Pitch 1.27 mm
Terminal Position QUAD
Width 16.586 mm
uPs/uCs/Peripheral ICs Type MICROCONTROLLER
