AT24C16C-STUM-T データシート

Name: AT24C16C-STUM-T
Brand: ATMEL
SKU: 110187755-0000-0000-0000

AT24C16C-STUM-T - ATMEL の商品詳細ページです。

２営業日以内に回答いたします

AT24C16C-STUM-T の詳細情報

型番	AT24C16C-STUM-T
メーカー	ATMEL
データシート
Additional Feature	ALSO OPERATES AT 0.4MHZ AT 1.7-5.5 SUPPLY VOLTAGE
Clock Frequency-Max (fCLK)	1 MHz
Data Retention Time-Min	100
Endurance	1000000 Write/Erase Cycles
I2C Control Byte	1010DDDR
JESD-30 Code	R-PDSO-G5
JESD-609 Code	e3
Length	2.9 mm
Memory Density	16384 bit
Memory IC Type	EEPROM
Memory Width	8
Moisture Sensitivity Level	1
Number of Functions	1
Number of Ports	1
Number of Terminals	5
Number of Words	2048 words
Number of Words Code	2K
Operating Mode	SYNCHRONOUS
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Organization	2KX8
Output Characteristics	OPEN-DRAIN
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSOP5/6,.11,37
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Parallel/Serial	SERIAL
Peak Reflow Temperature (Cel)	260
Power Supplies	1.8/5 V
Programming Voltage	3 V
Qualification Status	Not Qualified
Seated Height-Max	1 mm
Serial Bus Type	I2C
Standby Current-Max	1.0E-6 Amp
Supply Current-Max	0.003 mA
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	1.7 V
Supply Voltage-Nom (Vsup)	2.5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Width	1.6 mm
Write Cycle Time-Max (tWC)	5 ms
Write Protection	HARDWARE
